Manual 2100-404D
Page 13 of 19
FIGURE 7
ELECTRIC HEAT CLEARANCE
WARNING
A
minimum
of 1/4 inch clearance must be maintained between
the supply air duct and combustible materials. This is required
for the first 3 feet of ducting.
It is important to insure that the 1/4 inch minimum spacing is
maintained at all points.
Failure to do this could result in overheating the combustible
material and may result in a fire causing damage, injury or death.
Side section view of supply air duct for
wall mounted unit showing 1/4 inch
clearance to combustible surfaces.
