Aube Technologies TH146-P-U Thermostat User Manual



TH146-P-U 400-280-010-B 5/24/07 5/12
Wiring Diagram: 2H1C Heat Pump — New Installation
AC146-410
AC144-03
CT241
Humidifier
Dehumidifier
Compressor
Auxiliary Heat
Reversing Valve
Fan
Fault
Defrost
Dual Energy
