The ECONO mode has two (2) programs in which the
day, the time and the setpoint have to be pro-
grammed. For instance, this operating mode can be
used for a cottage installation where the user goes only
on weekends.
Program 1: Friday 3:00 PM, 20 °C (68 °F)
Program 2: Friday 8:00 PM, 15 °C (59 °F)
The temperature will be maintained at 20 °C (68 °F)
Friday from 3:00 PM to 8:00 PM, and maintained
at 15 °C (59 °F) the rest of the week.
This gives you a comfortable temperature at your
arrival and if you are not going to your cottage
for the weekend, there will be only a minimal
heating period.
To see the ECONO programs, select the ECONO
operating mode and press on P button successively
to see programs 1 and 2 appear on the display. In
ECONO mode, by pressing once on or , the
display shows the temperature setting. All subsequent
pressures will override your programming up to the
next program.
PROGRAMMING
1) Adjustment of time and day
Note: Select your OPTIONS before adjusting your time, because using the
RESET button will set the time back to default 0:00 MO (Monday).
Example of setting: Thursday 8:15 AM
Use D, H and M buttons to set the time. Once
set, press on R button to exit the time and day
adjustment mode.
Note 2
:The thermostat has an automatic return.
When such functions as time recording, pro-
grams recording, etc., are not completed by
pressing on return (R) button, the
thermostat will automatically exit the mode
after 60 seconds.
2) Typical suggested programs
This thermostat can store up to four (4) daily programs for weekdays and four
(4) daily programs for the weekend. Also, there is two (2) programs for the
ECONO mode. To practice programming use the following example.
Program number Time
Temperature setting
Weekday programs (Mon...Friday)
Program 1 6:30 AM 20 °C (68 °F)
Program 2 8:30 AM 15 °C (59 °F)
Program 3 4:30 PM 20 °C (68 °F)
Program 4 11:00 PM 15 °C (59 °F)
Weekend programs (Sat & Sun)
Program 1 7:00 AM 20 °C (68 °F)
Program 2 8:30 AM 15 °C (59 °F)
Program 3 4:30 PM 20 °C (68 °F)
Program 4 11:00 PM 15 °C (59 °F)
ECONO mode programs (weekend cottage)
Program 1 Friday 3:00 PM 20 °C (68 °F)
Program 2 Friday 8:00 PM 15 °C (59 °F)
Press on P button again to record or modify
weekday programs 2, 3 and 4 and weekend
programs 1, 2, 3 and 4.
Use H, M, or buttons to modify
the time and setpoint of programs.
Programming is now completed. Press on R
button or wait for the "automatic return"
to exit the programming mode.
Note: A program time left at -- -- : -- --
is considered inactive.
Select the ECONO mode.
Press on P button once.
The default values or the last recording
of program 1 will be displayed.
The default values are :
• 20 °C (68 °F) and the time -- -- : -- -- .
Use D, H, M and or buttons to record
the day, the time and the setpoint of program 1.
Press a second time on P button.
The default values or the last recording
of program 2 will be displayed.
Use D, H, M and or buttons to modify
the day, time and setpoint of program 2.
Programming is now completed. Press on R
button or wait for the "automatic return"
to exit the programming mode.
4) Recording the ECONO programs
To reset a program, use P button to select the program, then press
on MODE button.
To review programs, press on P button successively to see the programs
one after the other and make modifications if required.
CHARACTERISTICS
- Model: TH110-SP-P
- Electronic programmable thermostat
- Supply: 240 VAC, 50/60 Hertz
- Load: 20 A maximum, 1 HP
- Power: 4800 W @ 240 VAC
- Power consumption (off): 860 mW
- Approvals: CSA NRTL/C
- Display range: 0 °C to 99 °C (0 °F to 99 °F)
- Setting range: 5 °C to 27 °C (40 °F to 80 °F)
- Storage: -20 °C to 50 °C (-4 °F to 120 °F)
- Temperature regulation: 1 °C (1 °F)
- Precision: ± 0.5 °C (1 °F) (4800 W)
- 10 programs: 4 weekday programs, 4 weekend programs
and 2 ECONO programs
3) Recording the heating programs
Select the AUTO mode.
Press on P button once.
The default values or the last recording
of program 1 will be displayed.
The default values are:
• 20 °C (68 °F) and the time -- -- : -- --.
The days Monday to Friday are displayed to show
that this program is for weekdays.
AUBE TECHNOLOGIES INC. ONE (1) YEAR LIMITED WARRANTY
This product is warranted against material defects and workmanship in normal
use for a period of one year, from the date of the original purchase from autho-
rized dealers. During this period, AUBE technologies inc. will repair or replace
the product with a new or of equivalent quality at AUBE'S option, without
charge, any product proven defective in normal use.
Warranty does not cover transportation costs. Nor does it cover a product sub-
jected to misuse or accidental damage. This warranty does not cover the cost of
installation, removal or reinstallation.
This limited warranty is in lieu of all other warranties, obligations or liabilities
expressed or implied by the company. In no event shall AUBE technologies inc.
be liable for consequential or incidental damages resulting from installation of
this product. Some states or provinces do not allow limitations on how long an
implied warranty lasts, or the exclusion or limitation of incidental or conse-
quential damages, so the above exclusions or limitations may not apply to you.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
The defective product and the original sale receipt must be returned
to the original dealer or shipped pre-paid, insured and addressed to:
Aube technologies inc. • Customer Service • 705, Av. Montrichard
Iberville (Quebec) • J2X 5K8
If you have any questions concerning the installation or programming of this
product, please call our technical assistance at (450) 358-4600 for the Montreal
area or
1-800-831-AUBE for outside area, Monday to Friday between
8:30 AM and 5:00 PM Eastern time.
WARRANTY
Press on H and M buttons until 6:30 is displayed.
Press on or until 20 °C (68 °F) is displayed.
The first program is recorded.
Note 1: icon is showing you that the time
must be set.
ATTENTION: SEE TABLE PROBLEMS AND
SOLUTIONS ON ATTACHED ANNEXE.
720-110522-A 2/3
