ECONO
This mode automatically runs the programs of the
Econo schedule.
Press MODE until ECONO is outlined.
The current program number is displayed above the
ECONO icon.
The TH104 schedule offers 4 programs per day for the weekdays
and 4 programs per day for the weekend. There are no preset pro-
grams. The schedule maintains the setpoint associated to a pro-
gram until the beginning of the next one.
For maximum energy savings, the following schedule is recom-
mended:
To program this schedule
Before you start programming your thermostat, press MODE
until AUTO is selected (outlined).
! Press . The program number is displayed.
Weekdays are displayed (MOTUWETHFR).
" Use HOUR and MINUTE to set the time.
To skip a program (inactive --:--), do not set the time.
# Use the temperature adjustment buttons to define the setpoint.
$ Repeat steps 1 to 3 for remaining programs.
For the weekend programs:
% Press . The program number is displayed (1).
Weekend days are also displayed (SU and SA).
& Repeat steps 2 to 4.
' Press to exit programming mode.
Ideal for cottages, chalets or weekend residences, this schedule
enables the user to enter 2 settings.
The first setting lets the user enter a time (i.e. shortly before
expected arrival) at which the thermostat commands the heating
system to warm to comfort setpoint. The second setting commands
a temperature decrease.
Using the Econo Mode
At your arrival, switch to Automatic mode. The thermostat will run
your programs of the automatic schedule, keeping a comfortable
temperature during the day and decrease the temperature during
the night.
When you leave, switch to Econo mode. The thermostat will auto-
matically maintain the setpoint of the last program (e.g. 2) until the
beginning of the next program.
Programming the Econo Mode
Before you start programming your thermostat, press MODE
until ECONO is selected (outlined).
! Press . The program number is displayed (1).
" Press to select the expected arrival day.
# Use and to set the time.
$ Use the temperature adjustment buttons to define the setpoint.
% Press to select the next program (2).
& Repeat steps 2 to 4 to select the day, time and setpoint.
' Press to exit programming mode.
AUTOMATIC SCHEDULE
Programs Time Setpoint
Monday to Friday (same programs for all days of the week)
1 Morning 6:00 21°C
2 Day 8:00 17°C
3 Evening 17:00 21°C
4 Night 23:00 17°C
Saturday and Sunday (same programs for the weekend)
1 Morning 6:00 21°C
2 Day 8:00 17°C
3 Evening 17:00 21°C
4 Night 23:00 17°C
ECONO SCHEDULE
Programs Day Time Setpoint
1 Arrival (start heating) Friday 3:00 p.m. 21°C
2 End of heating period Friday 8:00 p.m. 15°C
3/4 400-104-000-A
