OPERATION
Operation modes
The thermostat has four (4) operation modes :
AUTO, MAN, STBY AND OFF.
They are selected through the MODE button. On display, the active
mode is framed. The frame moves on to the next mode each time
the MODE button is pressed.
NOTES :
When scrolling from the operation mode OFF to an active mode, the
thermostat will take 5 to 10 seconds to display the room temperature.
In normal use, the thermostat housing temperature can reach 35 °C to
45 °C.
The AUTOmatic mode
executes in sequence (hourly)
the programs recorded by the
user.
Pressing on the t or s button
displays the temperature
setting for five (5)econds.
The MAN operation mode
allows the user to bypass the
programming and holds the
present temperature.
The first time the t or s button
is pressed, the temperature
setting is displayed. For all
subsequent times pressed, the
temperature setting will change
1°C.
The STBY ( STANDBY) mode
allows an immediate adjustment
of the temperature setting. It is
factory set to 10 °C. User can
modify by refering to section:
PROGRAMMING THE STBY
MODE TEMPERATURE.
A pressure on the t or s button
displays the temperature
setting for five (5) seconds.
Why should you use the STBY
mode?
If you leave your home for the weekend and you wish to keep the
temperature to an economic level, instead of adjusting the
thermostat in manual mode and changing the setpoint of all units,
just set the thermostat in STBY mode.
In this mode, the electric heating system is turned off. Only the
time and the operation OFF mode framed are displayed.
CHARACTERISTICS
1) Proportional control
This thermostat works differently than the conventional
electro-mechanic one. The latter can have a variation of the set
temperature up to 4 °C while the electronic thermostat has a
variation of only 0.3°C. This slight oscillation eliminates the
discomfort of temperature variation often found with conventional
electro-mechanic thermostat.
The proportional controller determines the amount of power required
by the electric heating system to maintain the exact ambient
temperature of the temperature setting.
The display shows, in real
time, the applied power to the
electric heating system.
If you have set the switch #1
at position « ON » to control
a fan equipped system, the
display will show 100 % when
the heating system is turning
on and 0 % when it is OFF. In
that case, the temperature
regulation is +/- 0.5°C around
the set point.
2) Characteristics
- Model: TH101A
- Electronic Programmable line voltage thermostat (2 wires).
- Supply: 120/240 VAC, 50/60 Hz.
- Load: 16.6 Amp. maximum, 1.8 Amp minimum (Resistive only).
- Power: 4000 W / 240 VAC or 2000 W / 120 VAC.
- Power consumption (off) : 860mW.
- Approvals: CSA
- Display range: 0 to 40 °C (32 to 99 °F)
- Setting range: 5 to 35 °C (41 to 95 °F)
- Storage: -20 to 50 °C (-4 to 120 °F)
- Temperature control: 0.3 °C (SW1=Off), +/- 0.5 °C (SW1=On).
- Precision: ± 0.5°C (2500W), 0.9°C (4000W) of temperature setting.
- Six (6) programs: 4 weekday programs and 2 weekend programs.
WARRANTY
AUBE TECHNOLOGIES INC. LIMITED WARRANTY
This product is warranted against material defects and workmanship
in normal use for a period of one year, from the date of the original
purchase from authorized dealers. Warranty does not cover
transportation costs. Nor does it cover a product subjected to
misuse or accidental damage.
This limited warranty is in lieu of all other warranties, obligations or
liabilities expressed or implied by the company. In no event shall
AUBE Technologies inc. be liable for consequential or incidental
damages resulting from installation of the thermostat. Within this
period, any thermostat proven defective in normal use will be
repaired or replaced, at AUBE's option, without charge for either
parts or labor, provided that the thermostat with the original sale
receipt is returned to the original dealer or is shipped pre-paid,
insured and addressed to
AUBE Technologies inc.
Services centre
705 Montrichard Av., Saint-Jean-sur-Richelieu ( Quebec)
Canada J2X 5K8
AUTO
MAN
STBY
OFF
