STEP 4: CHECK OUT YOUR DOOR OPERATING SYSTEM
CAUTION: THERE ARE NO USER SERVICEABLE PARTS INSIDE
TRANSMITTER OR RECEIVER
A. After installing your receiver and transmitter, check the operation of your radio
controls by moving approximately 35 feet back from the garage door, then press
the transmitter button. Operation at this distance should be reliable.
B. If the transmitter doesn’t activate the operator, check the coding switches on both
the transmitter and receiver to assure an “exact” match. (See Fig. 2 & 3). This
may necessitate a reprogramming of a Quik Code Classic transmitter to match the
receiver coding switches.
C. If the distance is inadequate, check the battery and replace if necessary. (Also See
Step 4D).
D. To maximize the operating distance move the transmitter to different locations in
the car until a satisfactory distance is achieved.
E. If the receiver is in the proximity of a metal beam or other obstruction it may be
necessary to relocate the receiver to increase the operating range.
F. If multiple receivers are mounted closer than 15 feet, blocking and
interference may occur. Relocate the receivers farther apart.
G. If system does not work at any distance, check that the receiver terminals are
connected to the proper operator terminals. See Step 2A.
PART #107713 REV C
Manufacturer’s Limited Warranty
Allstar warrants its radio controls to be free from defect in material and workmanship for a
period of one (1) year from the date of purchase. To obtain service, contact your dealer.
To obtain service under this warranty the buyer must obtain authorization instructions for the
return of any goods from Allstar before returning the goods. The goods must be returned with
complete identification, with copy of proof-of-purchase, freight prepaid and in accordance
with Allstar’s instructions or they will not be accepted. In no event will Allstar be responsible
for goods returned without proper authorization or identification.
Goods returned to Allstar for warranty repair within the warranty period, which upon receipt
by Allstar are confirmed to be defective and covered by this limited warranty, will be repaired
or replaced at Allstar’s sole option, at no cost and returned pre-paid. Defective parts will be
repaired or replaced with new or factory rebuilt parts at Allstar’s sole option.
This limited warranty does not cover non-defect damage, damage caused by unreasonable use,
damage caused by improper installation or care, vandalism or lightning, fire or excessive heat,
flood or other acts of God (including, but not limited to misuse, abuse or alterations, failure to
provide reasonable and necessary maintenance), labor charges for dismantling or reinstalling a
repaired or replaced unit, or replacement batteries.
These warranties are in lieu of all other warranties, either expressed or implied. All implied
warranties of merchantability and/or fitness for a particular purpose are hereby disclaimed and
excluded. Under no circumstances shall Allstar be liable for consequential, incidental or
special damages arising in connection with the use or inability to use this product. In no event
shall Allstar’s liability for breach of warranty, breach of contract, negligence or strict liability
exceed the cost of the product covered hereby. No person is authorized to assume for Allstar
any other liability in connection with the sale of this product.
This warranty gives you specific legal rights. You may also have other rights which vary from
state to state. Warranty effective after July 1, 1998.
For Information:
Phone 610-873-6900 info@allstarcorp.com
FAX 610-873-6953 www.allstarcorp.com
A. Remove the access cover from the front of the
transmitter by sliding the cover away from the top of
the transmitter. (See Fig. 1A).
B. Use a small screwdriver or knife to remove small
door on back of receiver to gain access to coding
switches. (See Fig. 1B)
IMPORTANT: THE EXACT SAME CODE MUST
BE SET ON BOTH THE TRANSMITTER AND
RECEIVER. IF JUST ONE SWITCH IS
MISMATCHED THE CONTROLS WILL NOT
FUNCTION.
Note: If installing Allstar Classic Quik Code transmitter(s) with a 99xx or 88xx
Allstar Receiver, first set your receiver coding switches to your private code setting
using the instructions that follow THEN program your Allstar Classic Quik Code
transmitter (following the instructions included with the transmitter) to match the
receiver.
CAUTION: THE FACTORY PRESET CODE MUST BE
CHANGED TO SAFEGUARD AGAINST UNAUTHORIZED
OPERATION.
STEP 1: SET YOUR CODING SWITCHES
READ THE FOLLOWING INSTRUCTIONS
THOROUGHLY BEFORE STARTING INSTALLATION
Proper installation of your radio controls will assure
years of trouble-free operation.
Garage Door and Gate Operator Radio Controls
Models 9921, 9931, 8822, 8832, 8833
Installation Instructions
TRANSMITTER
Figure 1A
RECEIVER
Figure 1B
104384
104385
