NewAir 9701i Thermostat User Manual



What are the INSTALLER settings?
The INSTALLER SETTINGS are setup during the initial installation. They tell the thermostat how to function with your heating or cool-
ing equipment. The following is a brief overview and discussion of these settings.
SYSTEM SETUP
Choose the system component which the thermostat will control.
1st STAGE HEATING
The 9701i and the 9715i can have a gas/oil or electric first stage heating.
Choose the energy source for 1st stage heating.
19
INSTALL MENU
SELECT
1ST STAGE HEATING
GAS / OIL
ELECTRIC
HOME
SELECT
INSTALLER SETTINGS
INSTALLER SETTINGS
INSTALLER SETTINGS
HOME
MAIN MENU
SELECT
SELECT
SYSTEM SETUP GAS
RESIDUAL COOL 60
LOW BALANCE 45˚F
HIGH BALANCE 95˚F
AUTOCHANGEOVER OFF
EER ON
DEADBAND 3˚F
SECURITY OFF
SECURITY OFF
CONTACT INFO
SERVICE INT
REMINDER RUN
INSTALL MENU
SELECT
SYSTEM SETUP
FURNACE
HEAT PUMP
