DOOR CONTROL COMMAND 46
Description
There are three sub-functions within the door control function. They are CYCLE DOOR?, UNLOCK DOOR?, and
SECURE DOOR?.
CYCLE DOOR? momentarily unlocks a door to allow a person into an area. UNLOCK DOOR? unlocks a door to
allow free access. SECURE DOOR? unlocks a door and prohibits access regardless of a user’s authority level.
Using Door Control?
1. Ensure the display shows idle disarmed text.
2. Press the COMMAND bar. The display shows SYSTEM COMMAND.
3. Press 4 and 6.
NOTE: If you prefer, you may use the Function List in place of steps 2 and 3 to initiate this function. Press the
MENU key to enter the Function List, then press NEXT repeatedly until you reach the DOOR CTRL?
prompt. Press ENT.
4. The first sub-function that will appear is CYCLE DOOR? You can cycle through the three sub-functions by
pressing PREV and NEXT.
CYCLE DOOR?
5. If you wish to momentarily unlock an access door to allow a person into an area, press ENT at the CYCLE
DOOR ? prompt.
6. The display will read CYCLE 1 2 3 4 5 6 7 8 if all doors are at a normal state and are available. If a door is not at
a normal state, the number of the door would be replaced with a symbol indicated in the chart below:
7. Enter the number of the door you wish to cycle then press ENT. This door will be cycled and the display will
change to reflect the new status of the doors.
For example, if you wanted to cycle Door 3, at the following prompt:
CYCLE DOOR 1 2 3 4 5 6 7 8
press 3, then ENT. The display will read:
CYCLE DOOR 1 2 C 4 5 6 7 8
This indicates that all doors are at a normal state, except for Door 3, which is cycled.
8. Press ESC, to leave this subfunction, or enter another door number to cycle.
Symbol Meaning
--
Door is not active, not in scope, or user does not
have access level authority
C Door is on timed door sequence
U Strike and shunt are latched active (held open)
X Strike and shunt are deactivated (secured)
F There is a problem with the door. Call your security
company.
33267D 12/97
D9412/D7412 Owner’s Manual Supplement
Page 5
q
I have this feature.
q
I do not have this feature.
