TM
OWNER INSTALLATION AND
USER MANUAL Series 3000
Models 3214, 3314, 3316 & 3414
Automatic Garage Door Opener
For Sectional Overhead Residential Doors Only
DO NOT USE ON ONE PIECE DOORS
CONTENTS
Important Installation Instructions 2 Wireless Keyless Entry Installation 21
Features 4 Opening & Closing Force Adjustment
21
Door Tests 5 Contact Obstruction Sensing Adjustment
.
22
Pre-Assembly Check 5 Mechanical lock Adjustment 22
Installation Instructions 6 Operational Safety Rules 23
Installing Wall Station 8 Operation of Your Opener 24
Install Infrared Safety Sensors 10 Emergency Release Disconnect 26
Maintenance Schedule 27 Wall Station Code Change
and Programming
14
Trouble Shooting 28
Infrared Safety Sensors Alignment 15 Parts Breakdown-Rail Assembly 29
Transmitter Code Change & Programming 16 Parts Breakdown-Power Head Assembly
And Accessories
30
Travel Adjustment 19 Accessories 31
Obstruction Sensing Test 19 Warranty 32
Infrared Safety Sensor Obstruction Test 20 Customer Service Number 32
Copyright 2003 Wayne-Dalton Corp. Part No: 307545 Rev 3 12/3/2003
DOOR AND OPENER WILL NOT OPERATE PROPERLY UNTIL INFRARED SAFETY
SENSORS ARE INSTALLED AND PROPERLY ADJUSTED! DO NOT OPERATE DOOR
OPENER UNTIL FULLY INSTALLED, ADJUSTED & INSTRUCTED TO DO SO!
READ THE ENCLOSED INSTRUCTIONS CAREFULLY BEFORE
INSTALLING/OPERATING THIS OPENER! PAY CLOSE ATTENTION TO ALL
WARNING LABELS AND NOTES. THIS MANAUL SHOULD BE ATTACHED IN
CLOSE PROXIMITY TO THE G
A
RAGE DOOR OPENER.
