IMPORTANT NOTICES!
Wayne-Dalton highly recommends that you read and fully under-
stand the Installation Instructions and Owner’s Manual before you
attempt this installation.
To avoid possible injury, read the enclosed instructions carefully
before installing and operating the garage door. Pay close attention
to all warnings and notes. After installation is complete, fasten this
manual near garage door for easy reference.
The complete Installation Instructions and Owner’s Manual are
available at no charge from:
Wayne-Dalton, a Division Of Overhead Door Corporation,
P.O. Box 67, Mt. Hope, OH., 44660,
Or Online At www.Wayne-Dalton.com
Standard Lift
MH
inStaLLation inStructionS and owner’S ManuaL
e x t e n S i o n
Models: 105/110,
310/311
T a b l e O f C o n t e n t s
347752 REV1 03/08/2012
©Copyright 2012 Wayne-Dalton, a Division Of Overhead Door Corporation
Parts Breakdown 2
Pre-Installation 3
Important Safety Instructions 3
Tools Required 3
Package Contents 3
Door Section Identification 4
Graduated End Hinge And Strut Identification 4
Removing an Existing Door 5
Preparing the Opening 5
Installation 6
Optional Installation 14
Door Arm Hookup 14
Lift Handles 14
Pull Down Rope 14
Maintenance 15
Cleaning Your Garage Door 15
Painting Your Garage Door 15
Clear Or Stained Finishes 15
Operation and Maintenance 15
Warranty 17
Dealer Locator Information 18
