DOUBLE DOOR SCREEN FACE KIT
MODELS DESIGNER™ AND RAVENNA™
INSTALLATION INSTRUCTIONS FOR INSTALLING DOUBLE DOOR SCREEN FACE
KITS FOR USE WITH DESIGNER AND RAVENNA GAS FIREPLACE INSERTS
775,278M
Rev. A, 10/2008
HEARTH PRODUCTS
KITS AND ACCESSORIES
D
R
A
F
T
1
0
/
0
8
/
2
0
0
8
KIT CONTENTS (See Figure 1):
1 ea. Black Screen Face Assembly
1 ea. Instruction Sheet
TOOLS NEEDED:
None
Read this instruction sheet in its entirety before beginning the installa-
tion.
All of these parts may scratch and bend, great care should be used
in handling them.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
INSTALLATION INSTRUCTIONS
The four hanging brackets are pre-mounted onto the back of the screen
face. To install the screen face on the Designer or Ravenna gas insert, align
the four hanging brackets with their corresponding mounting brackets,
located on the left and right side of the insert. Set the hanging brackets
onto the mounting brackets and slide the face down until the brackets
are fully seated (see Figure 1).
Cat. No. Model Description
75028 SCREEN-DBV-RDV Screen Face/Double Door/Black
Figure 1
1
GENERAL INFORMATION
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Printed in U.S.A. © 2008 Lennox Hearth Products
P/N 775,278M Rev. A 10/2008
Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult
your local distributor for fireplace code information.
Lennox Hearth Products
1110 West Taft Avenue • Orange, CA 92865
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
