NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE
Lennox’s End Panel Assembly, Models 38AEP, 38AEP-BB and 38AEP-
BS are designed to be installed on Lennox’s Merit Plus fireplace, Model
CPF-38, along with the aluminum bi-fold glass door, Models 38ABF,
38ABF-BB and 38ABF-BS.
Please read and understand these instructions carefully before begin-
ning installation and operation. Do not attempt to modify the construc-
tion of this panel assembly as it could cause a malfunction or possible
fire hazard.
The end panel, Models 38AEP, 38AEP-BB and 38AEP-BS have been
tested and listed by Omni Test Laboratories, Inc.
INSTALLATION
The CPF-38 fireplace upper and lower frames have pre-formed holes for
mounting the end panel.
Insert the upper pins (longer) of the end panel assembly into the holes
in the upper fireplace frame. Swing the lower portion of the end panel
towards the lower fireplace frame and insert the two (2) lower pines
(shorter) into the two (2) holes in the lower frame.
Complete the installation by attaching the 38ABF, 38ABF-BB or 38ABF-
BS bi-fold door in the same manner. Refer to the 38ABF, 38ABF-BB and
38ABF-BS Installation Instructions (P/N 750,133M) for installation
requirements.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.
FIREPLACE KITS
AND ACCESSORIES
INSTALLATION INSTRUCTIONS FOR END PANEL ASSEMBLY
MODELS 38AEP, 38AEP-BB AND 38AEP-BS
END PANEL ASSEMBLY
750,132M
REV. A 01/2007
