Installation Manual of Room Air Conditioner
No. Accessory parts
Remote controller
R-03 dry battery
Mounting plate
Drain hose
Steel nail, cement
Screw
Plastic cap
Drain-elbow
Cover
Cushion
Connecting cable
1
1
A
B
C
D
E
F
G
2
3
4
5
6
7
8
9
10
2
1
1
6
4
1
1
4
1
Number
of
articles
Accessory parts
Optional parts for piping
Mark
Parts name
more than 5cm
more than 10cm
more than 60cm
more than 15cm
Non-adhesive tape
The marks from to in the figure are the parts numbers.
The distance between the indoor unit and the floor should
be more than 2m.
more than 10cm
more than 10cm
more than 10cm
Adhesive tape
Saddle(L.S) with screws
Attention must be paid to
the rising up of drain hose
Arrangement of piping directions
Rear left
Rear
right
Left
Below
Right
Connecting electric cable
for indoor and outdoor
Drain hose
Heating insulating material
4X50
4X25
Piping hole cover
Read this manual before installation
1.Driver
2.Hacksaw
3.Hole core drill
4.Spanner(17,19 and 26mm)
5.Torque wrench(17mm,22mm,26mm)
6.Pipe cutter
7.Flaring tool
8.Knife
9.Nipper 12.Reamer
10.Gas leakage detector or
soap-and-water solution
11.Measuring tape
Explain sufficiently the operating means to the user
according to this manual.
A
G
Change for
fresh air box
Change for
fresh air
tube(suit)
Outlet joint
11
12
13
1
1
2
Screw
6
G
F
A
C
D
E
13
12
Note:1.Cooling only units don't have Drain-elbow
Outlet joint
1
2. is only for the models of 18,22.
3.The models ZF don't have fresh function
and accessory parts related with freshing.
Drawing for the installation of indoor and outdoor units
Necessary Tools for Installation
15
14
14
