©2004 Edelbrock Corporation
Brochure #63-0232
Rev. 1/04
MC
©2004 Edelbrock Corporation
Brochure #63-0232
Rev. 1/04
MC
Please study these instructions carefully before installing your new Edelbrock water pump. Failure to follow instruction will void warranty
and may cause damage to parts and/or personal injury. If you have any questions or problems, please call our Technical Hotline at: 1-800-416-
8628, 7:00 am – 5:00 pm, Pacific Standard Time, Monday through Friday or e-mail us at Edelbrock@Edelbrock.com.
PLEASE complete and mail
your warranty card. Be sure to write the model number of this product in the “Part #____” space.
• DESCRIPTION: The Edelbrock aluminum water pump is a heavy-duty water pump for both street and racing applications. The pump is externally
the same as the original equipment pump (Ford #E9TE-8505-A4A) to provide compatibility with all accessories and pulleys. It offers increased
durability and cooling potential. Part #8045 is a reverse rotation water pump for 1994-1995, 5.0L V8s with serpentine drive belt. Not
for early
standard rotation 289-302 engines. Polished aluminum water pump Part #8046 fits the same applications as Part #8045.
• INSTALLATION: Installation is the same as for original equipment water pumps. Consult service manual for specific procedures, if necessary.
• CAUTION: Be sure that fan bolts don't protrude through the hub so far that they hit the water pump housing. NOTE: Remove two screws from
backing plate and apply RTV silicone to gasket just before installation. Re-assemble backing plate and install on engine using RTV silicone.
• SPECIAL NOTES: Check closely for any interference with drive belts; some filing for clearance may be necessary with some applications.
• SPECIFICATIONS: Dimension from block surface to hub: Part #8045 - 5-3/4”.
• THANK YOU.
®
VICTOR SERIES ALUMINUM WATER PUMPS
For 1994-1995 F-Series Trucks
with 5.0L, with Serpentine Belt
Catalog #8045 (Unpolished) and #8046 (Polished)
INSTALLATION INSTRUCTIONS
Please study these instructions carefully before installing your new Edelbrock water pump. Failure to follow instruction will void warranty
and may cause damage to parts and/or personal injury. If you have any questions or problems, please call our Technical Hotline at: 1-800-416-
8628, 7:00 am – 5:00 pm, Pacific Standard Time, Monday through Friday or e-mail us at Edelbrock@Edelbrock.com. PLEASE complete and mail
your warranty card. Be sure to write the model number of this product in the “Part #____” space.
• DESCRIPTION: The Edelbrock aluminum water pump is a heavy-duty water pump for both street and racing applications. The pump is externally
the same as the original equipment pump (Ford #E9TE-8505-A4A) to provide compatibility with all accessories and pulleys. It offers increased
durability and cooling potential. Part #8045 is a reverse rotation water pump for 1994-1995, 5.0L V8s with serpentine drive belt. Not
for early
standard rotation 289-302 engines. Polished aluminum water pump Part #8046 fits the same applications as Part #8045.
• INSTALLATION: Installation is the same as for original equipment water pumps. Consult service manual for specific procedures, if necessary.
• CAUTION: Be sure that fan bolts don't protrude through the hub so far that they hit the water pump housing. NOTE: Remove two screws from
backing plate and apply RTV silicone to gasket just before installation. Re-assemble backing plate and install on engine using RTV silicone.
• SPECIAL NOTES: Check closely for any interference with drive belts; some filing for clearance may be necessary with some applications.
• SPECIFICATIONS: Dimension from block surface to hub: Part #8045 - 5-3/4”.
• THANK YOU.
®
VICTOR SERIES ALUMINUM WATER PUMPS
For 1994-1995 F-Series Trucks
with 5.0L, with Serpentine Belt
Catalog #8045 (Unpolished) and #8046 (Polished)
INSTALLATION INSTRUCTIONS
