Top Products
PRO AV HOME ENTERTAINMENT
CM7
TM
autoMated
swing arM Mount
Chief now offers the CM7
™
Swing Arm Mount, backed by CLO
Systems, within its line of Cinematic automated mounting solutions.
Designed for 40-63” flat panel TVs weighing up to 180 lbs (81.6 kg),
the CM7 provides ultra-smooth movement. This low-profile
mounting solution extends from the wall and swivels left and right
with automated tilt, all via remote control!
More Mounts in Motion!
A new Cinematic
™
Series addition, the CM7 swing
arm mount provides automated positioning at the
touch of a button!
new!
Features
n Universal IR Remote Control
n Mounts directly to studs for easy on-wall installation
n Sits flush against the wall at 4.6" (117 mm)
n 12" (305 mm) smooth extension
n IR Remote Control (with 2 presets) or RS232 Interface
n Hidden Cable Management
n Mechanism protected by decorative cover for a finished look
n UL and TUV Listed
n 1 Year Manufacturer Warranty (parts & labor)
Dimensions (HxWxD)
22.64" (575 mm) x 26.57" (675 mm) x 4.6–12" (117–305 mm)
TV Width Tilt/Swivel Range
40–44.9" (102–113 cm) +7˚/-20˚, 28˚ left/right
45–48.9" (114–123 cm)
+7˚/-20˚, 26˚ left/right
49–55.9" (124–140 cm) +7˚/-20˚, 23˚ left/right
56–61" (142–155 cm) +7˚/-20˚, 19˚ left/right
IR Remote Control
– Comes standard with two preset buttons
to remember the favorite positions.
Control Box
– Removable for easy access with a selector
switch and LED to select TV size
Programmed Flat Panel Size
– Able to select TV size (40", 50" or
60") to limit movement, protecting
wall and TV
CHIEF MANUFACTURING
n
A DIVISION OF MILESTONE AV TECHNOLOGIES INC.
n
www.chiefmfg.com
USA/INTERNATIONAL
n
P 800.582.6480/952.894.6280
n
F 877.894.6918/952.894.6918
n
chief@chiefmfg.com
CHIEF MOUNTS CANADA
n
P 877.345.4329
n
F 888.377.5314
n
info@chiefmounts.ca
MILESTONE EUROPE B.V.
n
P 31 (0)40 266862 0
n
F 31 (0)40 2668615
n
europe@milestoneav.com
MILESTONE ASIA PACIFIC LTD.
n
P 86 755 8996 9226
n
F 86 755 8996 9217
n
asiapacific@milestoneav.com
©2008 Milestone AV Technologies Inc. Printed in the USA. 700083B 1/08. Chief is a registered trademark of Milestone AV Technologies Inc. All other brand names or
marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
Low Profile
Tilt
Extend & Swivel
Cable Management
– AV wires and cords are concealed by
routing them through the enclosure
