INSTALLATION
WHERE TO INSTALL CO ALARMS
The National Fire Protection Association (NFPA) recommends that a CO
Alarm should be centrally located outside of each separate sleeping
area in the immediate vicinity of the bedrooms. For added protection,
install additional CO Alarms in each separate bedroom, and on every
level of your home.
If your bedroom hallway is longer than 40 feet (12 meters), install a CO
Alarm at BOTH ends of the hallway.
In a Single-level Home:
•
Install at least one CO Alarm near or within each separate sleeping
ar
ea.
• For added protection, install an additional CO Alarm at least 20 feet
(6 meters) away from the furnace or fuel burning heat source.
In a Multi-level Home:
•
Install at least one CO Alarm near or within each separate sleeping
area.
• For added protection, install at least one CO Alarm on each level of
the home.
• For added protection, install an additional CO Alarm at least 20 feet
(6 meters) away from the furnace or fuel burning heat source.
This unit should receive continuous electrical power. Choose an
outlet where it cannot be accidentally unplugged or switched off by
childr
en. Keep small childr
en away from the unit. Teach them not to
play with it or unplug it. Explain what the alarms mean.
WHERE CO ALARMS SHOULD NOT BE
INST
ALLED
DO NOT LOCA
TE THIS CO ALARM:
• In garages, kitchens, furnace rooms, or in any extremely dusty,
dirty or gr
easy ar
eas.
• Closer than 15 feet (4.6 meters) from a furnace or other fuel
burning heat source, or fuel burning appliances like a water heater.
• Within 5 feet (1.5 meters) of any cooking appliance.
•
In extremely humid areas. This Alarm should be at least 10 feet (3
meters) fr
om a bath or shower
, sauna, humidifier
, vaporizer
, dish
-
washer
, laundry r
oom, utility r
oom or other sour
ce of high humidity
.
•
In ar
eas where temperature is colder than 40˚ F (4˚ C) or hotter
than 100˚ F (38˚ C). These areas include non-airconditioned crawl
spaces, unfinished attics, uninsulated or poorly insulated ceilings,
por
ches, and garages.
• In turbulent air, like near ceiling fans, heat vents, air conditioners,
fresh air returns, or open windows. Blowing air may prevent CO
from reaching the sensors.
•
In direct sunlight.
• In outlets covered by curtains or other obstruction.
• This CO Alarm is designed for use inside a single-family home
or apartment. It is not meant to be used in common lobbies,
hallways, or basements of multi-family buildings unless work-
ing CO Alarms are also installed in each family living unit.
CO Alarms in common areas may not be heard from inside
individual family living units.
• This CO Alarm alone is not a suitable substitute for complete
detection systems in places which house many people, like
hotels or dormitories, unless a CO Alarm is also placed in each
unit.
• DO NOT use this CO Alarm in warehouses, industrial or com-
mer
cial buildings, special-purpose non-residential buildings, or
airplanes. This CO Alarm is specifically designed for residential
use, and may not provide adequate protection in non-residential
applications.
USER’S MANUAL
120V PLUG-IN CARBON MONOXIDE ALARM
WITH SILENCE FEA
TURE
Model
CO600
Printed in Mexico M08-0152-002 S 07/07
IMPORTANT!
PLEASE READ CAREFULLY AND SAVE.
This user’s manual contains important information about your Carbon
Monoxide (CO) Alarm’s operation. If you are installing this CO Alarm
for use by others, you must leave this manual—or a copy of it—with
the end user.
TABLE OF CONTENTS
Intr
oduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Basic Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
How Your CO Alarm Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Understanding Your CO Alarm . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Where to Install CO Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Where CO Alarms Should NOT Be Installed . . . . . . . . . . . . . . . .2
How to Install Your CO Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . .3
If Y
our CO Alarm Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
If the Alarm Signal Sounds
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Using the Silence Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Testing and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Weekly Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
What You Need To Know About CO . . . . . . . . . . . . . . . . . . . . . . . . . .4
What is CO? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Symptoms of CO Poisoning . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Finding the Source of CO After an Alarm . . . . . . . . . . . . . . . . . .4
Potential Sources Of CO In The Home . . . . . . . . . . . . . . . . . . . .4
How Can I Protect My Family? . . . . . . . . . . . . . . . . . . . . . . . . . .4
Regulator
y Information for CO Alarms . . . . . . . . . . . . . . . . . . . . . .5-6
General Limitations Of CO Alarms . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
© 2007 BRK Brands, Inc., a Jarden Corporation company (NYSE: JAH)
3901 Liberty Street Road, Aurora, IL 60504-8122
All rights reserved.
Consumer Affairs: (800) 323-9005 • www.firstalert.com
INTRODUCTION
BASIC SAFETY INFORMA
TION
• Dangers, Warnings, and Cautions alert you to important
operating instructions or to potentially hazardous situations.
Pay special attention to these items.
• THIS IS NOT A SMOKE ALARM! This CO Alarm is designed to
detect carbon monoxide from ANY source of combustion. It is
NOT designed to detect smoke, fir
e, or any other gas.
•
This CO Alarm is approved for use in single-family residences.
•
This CO Alarm will only indicate the presence of carbon
monoxide gas at the sensor
. Carbon monoxide gas may be
pr
esent in other areas.
•
The Silence Feature is for your convenience only and will not
correct a CO problem. Always check your home for a potential
pr
oblem after any alar
m. Failur
e to do so can r
esult in injur
y or
death.
• This CO Alarm should receive continuous 120VAC, 60 Hz, pure
sine wave electrical power. Do not use in an extension cord or
outlet contr
olled by a dimmer or switch.
• NEVER ignore your Carbon Monoxide Alarm if it alarms. Refer
to “If Your CO Alarm Sounds” for more information. Failure to
do so can r
esult in injury or death.
•
Test the CO Alarm once a week. If the CO Alarm ever fails to
test cor
r
ectly
, have it r
eplaced immediately! If the CO Alar
m is
not working pr
operly
, it cannot aler
t you to a pr
oblem.
•
This pr
oduct is intended for use in ordinary indoor locations of
family living units. It is not designed to measure CO levels in
compliance with Occupational Safety and Health Administration
(OSHA) commer
cial or industrial standards. Individuals with
medical conditions that may make them more sensitive to
carbon monoxide may consider using warning devices which
pr
ovide audible and visual signals for carbon monoxide con-
centrations under 30 ppm. For additional information on carbon
monoxide and your medical condition contact your physician.
HOW YOUR CO ALARM WORKS
GENERAL INFORMA
TION
Leave your CO Alarm plugged in year-round. CO problems can
occur any time during the year
, and this Alarm can only alert you if
it is plugged in and receiving power.
When fully powered, the unit samples the air and takes a new reading
about every second. A microchip inside the unit stores each reading,
and remembers the levels of CO it has been exposed to over time.
The Alarm sounds when it has been exposed to a “critical” level of CO
(measured in parts per million or “ppm”) within a specified time (meas-
ured in minutes). This CO Alarm features a permanently installed sensor,
an indicator light, and an 85 dB alarm horn. It also has a Silence
Feature to temporarily quiet the alarm horn.
MALFUNCTION WARNING
This unit performs daily self-diagnostic tests. If the Alarm malfunctions,
it should be r
eplaced immediately
.
THE COVER OF YOUR CO ALARM
1 2 3 4 5
LIMITED W
ARRANTY
BRK Brands, Inc. ("BRK") the maker of First Alert
®
brand pr
oducts, warrants that for a period of 5 years fr
om the date of purchase, this product
will be free from defects in material and workmanship. BRK, at its option, will repair or replace this product or any component of the product
found to be defective during the warranty period. Replacement will be made with a new or remanufactured product or component. If the
pr
oduct is no longer available, r
eplacement may be made with a similar pr
oduct of equal or gr
eater value This is your exclusive warranty
.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original sales
r
eceipt. Pr
oof of pur
chase is r
equir
ed to obtain warranty performance. BRK dealers, service centers, or retail stores selling BRK products do
not have the right to alter, modify or any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage r
esulting fr
om any of the following: negligent use or misuse of the pr
oduct, use
on improper voltage or current, use contrary to the operating instructions, disassembly, repair or alteration by anyone other than BRK or an
authorized service center. Further, the warranty does not cover acts of God, such as fire, flood, hurricanes and tornadoes or any batteries that
ar
e included with this unit.
BRK shall not be liable for any incidental or consequential damages caused by the breach of any express or implied warranty. Except to the
extent pr
ohibited by applicable law
, any implied warranty of mer
chantability or fitness for a particular purpose is limited in duration to the
duration of the above warranty
. Some states, pr
ovinces, or jurisdictions do not allow the exclusion or limitation of incidental or consequential
damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you. This warranty gives
you specific legal rights, and you may also have other rights that vary from state to state, or province to province.
How to Obtain Warranty Service
Ser
vice:
If service is r
equir
ed, do not r
etur
n the product to your retailer. In order to obtain warranty service, contact the Consumer Affairs
Division at 1-800-323-9005, 7:30 AM to 5:00 PM, Central Standard Time, Monday through Friday. To assist in serving you, please have the
model number and date of purchase available when calling.
For W
ar
ranty Ser
vice r
etur
n to:
BRK Brands, Inc., 25 Spur Drive, El Paso, TX 79906
6
1 Test/Silence Button 2 POWER/ALARM Light (Red)
3 (Behind Cover) Alarm Horn: 85 dB audible alarm
for test, alarm, and unit malfunction war
ning
UNDERSTANDING YOUR CO ALARM
WHAT YOU SEE AND HEAR DURING INSTALLATION
GARAGE
SUGGESTED AREAS FOR INSTALLING ADDITIONAL CO ALARMS
BEDROOM
BEDROOM
HALL
LIVING ROOM
KITCHEN
B
ASEMENT
BEDROOM
R
EQUIRED TO MEET NFPA RECOMMENDATIONS
HOW TO INSTALL YOUR CO ALARM
Read “Where To Install Your CO Alarm” before starting.
Before you start installation,
find the pair of self-adhesive labels
included with this CO Alarm. On each label write in the phone number
of your emergency responder (like 911) and a qualified appliance tech-
nician. Place one label near the CO Alarm, and the other label in the
“fresh air” location you plan to go if the alarm sounds.
1. Plug the unit into a standard
UNSWITCHED 120V AC outlet.
The unit should be located
where it can wake you if it
alarms at night.
2. Make sure the POWER/ALARM light
shines continuously when you plug it.
3. Test by pressing the Test/Silence button firmly until the unit sounds:
four loud beeps, pause, 4 beeps. During testing, the POWER/
ALARM light will flash rapidly. This is normal.
IF YOUR CO ALARM SOUNDS
Actuation of your CO Alarm indicates the presence of carbon
monoxide (CO) which can kill you. In other words, when your CO
Alarm sounds, you must not ignore it!
IF THE ALARM SIGNAL SOUNDS:
1. Operate the Test/Silence button.
2. Call your emergency services, fire department or 911. Write down
the number of your local emergency service here:
_____________________________________________________________
3.
Immediately move to fresh air—outdoors or by an open door or
window. Do a head count to check that all persons are accounted
for. Do not re-enter the premises, or move away from the open door
or window until the emergency services responder has arrived, the
premises have been aired out, and your CO Alarm remains in its
normal condition.
4. After following steps 1-3, if your CO Alarm reactivates within a
24-hour period, repeat steps 1-3 and call a qualified appliance
technician to investigate for sources of CO from fuel-burning
equipment and appliances, and inspect for proper operation of this
equipment. If problems are identified during this inspection have the
equipment serviced immediately. Note any combustion equipment
not inspected by the technician, and consult the manufacturers’
instructions, or contact the manufacturers directly, for more
information about CO safety and this equipment. Make sure that
motor vehicles are not, and have not, been operating in an attached
garage or adjacent to the residence. Write down the number of a
qualified appliance technician here:
_____________________________________________________________
Alarms have various limitations. See "General Limitations of CO
Alarms" for details.
USING THE SILENCE FEATURE
The Silence Featur
e is for your convenience only and will not cor
r
ect
a CO problem. Always check your home for a potential problem
after any alarm. Failure to do so can result in injury or death.
NEVER unplug your CO Alarm to silence the horn. Use the silence
feature. Unplugging the CO Alarm removes your protection! See “If
Your CO Alarm Sounds” for details on responding to an alarm.
When CO reaches alarm levels the alarm will sound— repeating horn
patter
n: 4 beeps, a pause, 4 beeps, etc. Pr
ess and hold the T
est/Silence
button until the horn is silent. The initial Silence cycle will last approxi-
mately 4 minutes.
NOTE: After initial 4-minute Silence cycle, the CO Alarm re-evaluates
present CO levels and responds accordingly. If CO levels remain poten-
tially dangerous—or start rising higher—the horn will start sounding
again.
While the detector is silenced:
“ALARM-MOVE TO FRESH AIR”
If you hear the alar
m horn and the red light is flashing,
move ever
yone to a source of fresh air.
DO NOT unplug the CO Alarm!
WHAT YOU NEED TO KNOW ABOUT CO
WHAT IS CO?
CO is an invisible, odorless, tasteless gas produced when fossil fuels
do not burn completely, or are exposed to heat (usually fire). Electrical
appliances typically do not produce CO.
These fuels include: Wood, coal, charcoal, oil, natural gas, gasoline,
kerosene, and propane.
Common appliances are often sources of CO. If they are not properly
maintained, are improperly ventilated, or malfunction, CO levels can rise
quickly. CO is a real danger now that homes are more energy efficient.
“Air-tight” homes with added insulation, sealed windows, and other
weatherproofing can “trap” CO inside.
SYMPTOMS OF CO POISONING
These symptoms are related to CO POISONING and should be
discussed with ALL household members.
Mild Exposure:
Slight headache, nausea, vomiting, fatigue (“flu-like” symptoms).
Medium Exposure:
Throbbing headache, drowsiness, confusion, fast heart rate.
Extreme Exposure:
Convulsions, unconsciousness, heart and lung failure. Exposure to
carbon monoxide can cause brain damage, death.
Some individuals are more sensitive to CO than others, including
people with cardiac or respiratory problems, infants, unborn
babies, pregnant mothers, or elderly people can be more quickly
and severely affected by CO. Members of sensitive populations
should consult their doctors for advice on taking additional
precautions.
FINDING THE SOURCE OF CO AFTER AN ALARM
Carbon monoxide is an odorless, invisible gas, which often makes it
difficult to locate the source of CO after an alarm. These are a few of
the factors that can make it difficult to locate sources of CO:
• House well ventilated before the investigator arrives.
• Problem caused by “backdrafting.”
• Transient CO problem caused by special circumstances.
Because CO may dissipate by the time an investigator arrives, it may be
dif
ficult to locate the source of CO.
BRK Brands, Inc. shall not be obli
-
gated to pay for any carbon monoxide investigation or ser
vice call.
POTENTIAL SOURCES OF CO IN THE HOME
Fuel-burning appliances like: portable heater, gas or wood burning
fireplace, gas kitchen range or cooktop, gas clothes dryer.
Damaged or insufficient venting: corroded or disconnected water
heater vent pipe, leaking chimney pipe or flue, or cracked heat
exchanger, blocked or clogged chimney opening.
Improper use of appliance/device: operating a barbecue grill or
vehicle in an enclosed area (like a garage or screened porch).
T
ransient CO Pr
oblems:
“transient” or on-again-of
f-again CO pr
oblems
can be caused by outdoor conditions and other special cir
cumstances.
The following conditions can result in transient CO situations:
1. Excessive spillage or reverse venting of fuel appliances caused by
outdoor conditions such as:
• Wind direction and/or velocity, including high, gusty winds. Heavy
air in the vent pipes (cold/humid air with extended periods
between cycles).
• Negative pressure differential resulting from the use of exhaust
fans.
•
Several appliances running at the same time competing for limited
fresh air.
• Vent pipe connections vibrating loose from clothes dryers,
fur
naces, or water heaters.
• Obstructions in or unconventional vent pipe designs which can
amplify the above situations.
2.
Extended operation of unvented fuel bur
ning devices (range, oven,
fir
eplace).
3. Temperature inversions, which can trap exhaust close to the ground.
4.
Car idling in an open or closed attached garage, or near a home.
These conditions are dangerous because they can trap exhaust in your
home. Since these conditions can come and go, they are also hard to
recreate during a CO investigation.
HOW CAN I PROTECT MY FAMILY?
A CO Alarm is an excellent means of protection. It monitors the air and
sounds a loud alarm before carbon monoxide levels become threaten-
ing for average, healthy adults.
A CO Alar
m is not a substitute for pr
oper maintenance of home
appliances.
To help prevent CO problems and reduce the risk of CO poisoning:
•
Clean chimneys and flues yearly
. Keep them fr
ee of debris, leaves,
and nests for proper air flow. Also, have a professional check for
rust and corrosion, cracks, or separations. These conditions can
pr
event pr
oper air movement and cause backdrafting. Never “cap”
or cover a chimney in any way that would block air flow.
• Test and maintain all fuel-burning equipment annually. Many
local gas or oil companies and HVAC companies offer appliance
inspections for a nominal fee.
• Make regular visual inspections of all fuel-burning appliances.
Check appliances for excessive rust and scaling. Also check the
flame on the burner and pilot lights. The flame should be blue.
A yellow flame means fuel is not being burned completely and CO
may be pr
esent. Keep the blower door on the furnace closed. Use
vents or fans when they are available on all fuel-burning appliances.
Make sure appliances are vented to the outside. Do not grill or
barbecue indoors, or in garages or on scr
een porches.
•
Check for exhaust backflow fr
om CO sour
ces. Check the draft
hood on an operating furnace for a backdraft. Look for cracks on
fur
nace heat exchangers.
• Check the house or garage on the other side of shared wall.
• Keep windows and doors open slightly. If you suspect that CO is
escaping into your home, open a window or a door
. Opening
windows and doors can significantly decr
ease CO levels.
In addition, familiarize yourself with all enclosed materials. Read
this manual in its entir
ety, and make sure you understand what to
do if your CO Alarm sounds.
WHAT LEVELS OF CO CAUSE AN ALARM?
Underwriters Laboratories Inc. Standard UL2034 requires residential CO
Alarms to sound when exposed to levels of CO and exposure times as
described below. CO levels are measured in parts per million (ppm) of
CO over time (in minutes).
UL2034 Required Alarm Points*:
• If the alarm is exposed to 400 ppm of CO, IT MUST ALARM
BETWEEN 4 and 15 MINUTES
• If the alarm is exposed to 150 ppm of CO, IT MUST ALARM
BETWEEN 10 and 50 MINUTES.
• If the alarm is exposed to 70 ppm of CO, IT MUST ALARM
BETWEEN 60 and 240 MINUTES.
* Approximately 10% COHb exposure at levels of 10% to 95% Relative
Humidity (RH).
The unit is designed not to alarm when exposed to a constant level
of 30 ppm for 30 days.
CO Alarms are designed to alarm before there is an immediate life
threat. Since you cannot see or smell CO, never assume it’s not present.
• An exposure to 100 ppm of CO for 20 minutes may not affect
average, healthy adults, but after 4 hours the same level may
cause headaches.
• An exposure to 400 ppm of CO may cause headaches in average,
healthy adults after 35 minutes, but can cause death after 2 hours.
This CO Alarm measures exposure to CO over time. It alarms if CO
levels are extremely high in a short period of time, or if CO levels reach
a certain minimum over a long period of time. The CO Alarm generally
sounds an alarm before the onset of symptoms in average, healthy
adults.
TESTING AND MAINTENANCE
WEEKLY TESTING
Pr
ess the T
est/Silence button on the Alarm cover until alarm sounds.
During testing, you will hear a loud alarm sequence – 4 beeps, pause,
4 beeps, pause.
The alarm sequence should last 5-6 seconds. If it does not alarm, make
sure the unit is fully plugged into an unswitched outlet. If the unit still
does not alarm, replace it immediately.
•
If the Alar
m ever fails to test pr
operly
, r
eplace it immediately
.
Pr
oducts under war
ranty may be r
etur
ned to the manufacturer
for replacement. See “Limited Warranty” at the end of this
manual.
• DO NOT stand close to the Alarm when the horn is sounding.
Exposure at close range may be harmful to your hearing. When
testing, step away when horn starts sounding.
• NEVER use vehicle exhaust! Exhaust may cause permanent
damage and voids your war
ranty.
REGULAR MAINTENANCE
T
o keep the CO Alar
m working pr
operly:
•
T
est it every week as described in “W
eekly T
esting.”
• Vacuum the CO Alarm cover at least once a month, using the soft
brush attachment. Never use water
, cleaners, or solvents, since
they may damage the unit. Test the Alarm again after vacuuming.
DO NOT spray cleaning chemicals or insect sprays directly on or
near the CO Alarm. DO NOT paint over the CO Alarm. Doing so
may cause permanent damage.
• Household cleaners, aerosol chemicals and other contaminants
can affect the sensor. When using any of these materials near the
CO Alarm, make sure the room is well ventilated.
• If your home is being fumigated, unplug the unit temporarily and
put it wher
e it will not be exposed to chemicals or fumes. When
fumigation is complete and all traces of fumes clear, plug the unit
back in and retest it.
This CO Alarm is intended for residential use. It is not intended for
use in industrial applications where Occupational Safety and Health
Administration (OSHA) requirements for carbon monoxide detectors
must be met.
CO alarms may not waken all individuals.
If children or others do not
readily waken to the sound of the CO alarm, or if there are infants or
family members with mobility limitations, make sure that someone is
assigned to assist them in the event of an emergency.
CO Alarms will not work without power. This CO Alarm requires a
continuous supply of AC power. Plug into an unswitched 120V AC outlet
only.
CO Alarms for Solar or Wind Energy users and battery backup
power systems: AC powered CO Alarms should only be operated with
true or pure sine wave inverters. Operating this CO Alarm with most
battery-powered UPS (uninterruptible power supply) products or square
wave or “quasi sine wave” inverters will damage the Alarm. If you are
not sure about your inverter or UPS type, please consult with the manu-
facturer to verify.
This CO Alarm will not sense carbon monoxide that does not reach
the sensor. This CO Alarm will only sense CO at the sensor. CO may be
present in other areas. Doors or other obstructions may affect the rate
at which CO reaches the CO Alarm. For this reason, if bedroom doors
are usually closed at night, we recommend you install a CO Alarm in
each bedroom and in the hallway between them.
CO Alarms may not sense CO on another level of the home. For
example, a CO Alarm on the second level, near the bedrooms, may not
sense CO in the basement. For this reason, one CO Alarm may not give
adequate warning. Complete coverage is recommended. Place CO
Alarms on each level of the home.
CO Alarms may not be heard. The alarm horn loudness meets or
exceeds current UL standards of 85 dB at 10 feet (3 meters). However,
if the CO Alarm is installed outside the bedroom, it may not wake up a
sound sleeper or one who has recently used drugs or has been drinking
alcoholic beverages. This is especially true if the door is closed or only
partly open. Even persons who are awake may not hear the alarm horn
if the sound is blocked by distance or closed doors. Noise from traffic,
stereo, radio, television, air conditioner, or other appliances may also
prevent alert persons from hearing the alarm horn. This CO Alarm is
not intended for people who are hearing impaired.
CO Alarms are not a substitute for a smoke alarm. Although fire is a
source of carbon monoxide, this CO Alarm does not sense smoke or
fire. This CO Alarm senses CO that may be escaping unnoticed from
malfunctioning furnaces, appliances, or other sources. Early warning of
fire requires the installation of smoke alarms.
CO Alarms are not a substitute for life insurance. Though these CO
Alarms warn against increasing CO levels, BRK Brands, Inc. does not
warrant or imply in any way that they will protect lives from CO poisoning.
Homeowners and renters must still insure their lives.
CO Alarms have a limited life. Although the CO Alarm and all of its
parts have passed many stringent tests and are designed to be as
reliable as possible, any of these parts could fail at any time. Therefore,
you must test your CO Alarm weekly
.
CO Alarms are not foolproof. Like all other electronic devices, CO
Alarms have limitations. They can only detect CO that reaches their
sensors. They may not give early warning to rising CO levels if the CO
is coming from a remote part of the home, away from the CO Alarm.
TROUBLESHOOTING GUIDE
PROBLEM...
THIS MEANS... YOU SHOULD...
Red light is OFF
. Unit will not alarm when you
pr
ess the Test/Silence button.
CO Alarms may not be plugged all the way in, or
is not r
eceiving power.
Gently push unit all the way into outlet. Make
sur
e it is not plugged into an outlet controlled by
a switch.
The light flashes (RED) and the hor
n sounds 3
quick “chirps” every minute.
MALFUNCTION SIGNAL. CO
Alarm needs to be
replaced.
Make sur
e unit is plugged in secur
ely
.
CO Alarms under warranty should be returned
to manufactur
er for r
eplacement. See “Limited
W
arranty” for details.
CO Alarm goes back into alarm 4 minutes after
you pr
ess the T
est/Silence button.
CO levels indicate a potentially danger
ous
situation.
IF YOU ARE FEELING SYMPTOMS OF CO
POISONING, EV
ACUA
TE your home and call 911
or the Fire Department. If not, press the Test/
Silence button again and keep ventilating your
home.
CO Alarm sounds frequently even though no high
levels of CO are revealed in an investigation.
The CO Alarm may be improperly located.
Refer to “Where to Install CO Alarms.”
Relocate your Alarm. If frequent alarms continue,
have home rechecked for potential CO problems.
You may be experiencing an intermittent CO
problem.
If you have any questions that cannot be answered by reading this manual, call Consumer Affairs at 1-800-323-9005.
120V AC
~,
60 Hz, 0.09A
Why is this important? Because you need to be warned of a potential
CO problem while you can still react in time. In many reported cases of
CO exposure, victims may be aware that they are not feeling well, but
become disoriented and can no longer react well enough to exit the
building or get help. Also, young children and pets may be the first
affected. The average healthy adult might not feel any symptoms when
the CO Alarm sounds. However, people with cardiac or respiratory
problems, infants, unborn babies, pregnant mothers, or elderly people
can be more quickly and severely affected by CO. If you experience
even mild symptoms of CO poisoning, consult your doctor immediately!
Standards: Underwriters Laboratories Inc. Single and Multiple Station
carbon monoxide alarms UL2034.
According to Underwriters Laboratories Inc. UL2034, Section 1-1.2:
“Carbon monoxide alarms covered by these requirements are intended
to respond to the presence of carbon monoxide from sources such as,
but not limited to, exhaust from internal-combustion engines, abnormal
operation of fuel-fired appliances, and fireplaces. CO Alarms are
intended to alarm at carbon monoxide levels below those that could
cause a loss of ability to react to the dangers of Carbon Monoxide
exposure.” This CO Alarm monitors the air at the Alarm, and is designed
to alarm before CO levels become life threatening. This allows you
precious time to leave the house and correct the problem. This is only
possible if Alarms are located, installed, and maintained as described in
this manual.
Gas Detection at Typical Temperature and Humidity Ranges: The
CO Alarm is not formulated to detect CO levels below 30 ppm typically.
UL tested for false alarm resistance to Methane (500 ppm), Butane (300
ppm), Heptane (500 ppm), Ethyl Acetate (200 ppm), Isopropyl Alcohol
(200 ppm) and Carbon Dioxide (5000 ppm). Values measure gas and
vapor concentrations in parts per million.
Audible Alar
m:
85 dB minimum at 10 feet (3 meters).
REGULATORY INFORMATION FOR CO ALARMS
GENERAL LIMITATIONS OF CO ALARMS
First Alert
®
is a registered trademark of the First Alert Trust.
Printed in Mexico M08-0152-002 S 07/07
WHEN YOU FIRST PLUG-IN THE CO ALARM:
HORN:
Silent
POWER/ALARM LIGHT: Shines continuously
UNDER NORMAL CONDITIONS (AC POWER):
HORN:
Silent
POWER/ALARM LIGHT: Shines continuously
WHEN YOU TEST THE CO ALARM:
HORN:
Sounds loudly - 4 beeps, pause, 4 beeps, pause
POWER/ALARM LIGHT: Flashes rapidly
WHAT YOU SEE AND HEAR UNDER DIFFERENT CONDITIONS:
WHEN THE ELECTRICITY COMES BACK ON AFTER A POWER
FAILURE:
HORN:
Silent
POWER/ALARM LIGHT: Shines continuously.
IF THE CO ALARM IS NOT OPERATING PROPERLY (MALFUNCTION
SIGNAL):
HORN:
Three rapid chirps every minute
POWER/ALARM LIGHT: Flashes three times in sync with the horn.
WHAT YOU SEE AND HEAR IF CO IS DETECTED:
ALARM LEVELS OF CO ARE DETECTED:
HORN:
Sounds loudly - 4 beeps, pause, 4 beeps, pause.
This sequence repeats for as long as the unit is in alarm.
POWER/ALARM LIGHT: Flashes rapidly
IF YOU SILENCE THE ALARM:
HORN:
Silent for about 4 minutes
POWER/ALARM LIGHT: Flashes rapidly
Note: After 4 minutes, if CO levels dr
op below alarm levels, the unit
will remain silent and return to normal operation. If CO presence
still indicates a potentially dangerous situation, the horn will sound
again.
IF THE CO LEVELS RETURN TO NORMAL:
HORN:
Silent
POWER/ALARM LIGHT: Shines continuously
For your records, please record:
Date Purchased: __________________
Wher
e Purchased: _______________________
Date Installed: ____________/____________Month/Y
ear
Replacement date is five years after installation:
_____________/____________Month/Year
NOTE: End of Life Signal — Once the unit r
eaches the end of
its lifecycle, the MALFUNCTION SIGNAL will sound once a
minute to indicate the need to immediately replace the Alarm.
If the CO Alarm...
Is silent for only 4 minutes,
then starts sounding loudly—
4 beeps, pause,
4 beeps, pause
This means...
CO levels ar
e still potentially
dangerous.
If the CO Alarm...
Remains silent after you
pr
essed the T
est/Silence
button
This means...
CO levels are dropping.
2
3
1
AC Plug
CONFORMS
TO UL 2034
