Manual 2110-1406B
Page 1 of 11
General Notes
Revised and/or additional pages may
be issued from time to time.
A complete and current manual
consists of pages shown in the
following contents section.
Important
Contact the installing and/or local Bard
distributor for all parts requirements.
Make sure you have the complete
model and serial number available
from the unit rating plates.
Contents
Description Page
Cabinet Components
Exploded View ...........................2
Usage List ..................................3
Usage List ..................................4
Functional Components
Exploded View ...........................5
Usage List ..................................6
Usage List ..................................7
Control Panel
Exploded View ...........................8
Usage List ..................................9
Usage List .................................10
Blower Assembly
Exploded View ..........................11
Usage List ................................. 11
Manual: 2110-1406B
Supersedes: 2110-1406A
File: Tab 16
Date: 11-05-13
WALL MOUNTED
PACKAGE AIR CONDITIONER
Models:
W42L2
W48L2
W60L2
W70L2
REPLACEMENT
PARTS MANUAL
Bard Manufacturing Company, Inc.
Bryan, Ohio 43506
Since 1914...Moving ahead, just as planned.
