RELIANT+
SINGLE CONTROL KITCHEN FAUCET
WITH CAST BRASS SPOUT
4205.001 Shown
MODEL NUMBER:
4205.001 Kitchen Faucet
Metal Lever Handle. Separate color-matched
handspray.
4205.000 Kitchen Faucet
Metal Lever Handle. Less handspray.
4205.003 Kitchen Faucet
Metal Lever Handle. Color-matched handspray through
escutcheon.
PRODUCT FEATURES:
Ceramic Disc Valve Cartridge: Assures a lifetime of
drip-free performance.
Cast Brass Waterway, Cast Brass Spout: Highest
quality faucet materials for durability and long life.
Higher and Longer Spout: Spout designed to allow more
room under spout and extended reach into the sink.
Memory Position Valving: Allows user to turn valve on
and off at preferred temperature setting without readjusting
handle position each time.
Adjustable Hot Limit Safety Stop: Limits the amount
of hot water allowed to mix with cold. Reduces the risk of
accidental scalding.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65
lead requirements.
Choice of Finishes: Wide range of durable finishes.
Simple Installation: Fast and easy one person installation.
Faucet drops in from top. Quick-spin nuts secure faucet in place.
SUGGESTED SPECIFICATION:
Single control kitchen faucet shall feature a cast brass body and swivel spout, and all metal handle. Shall also feature
washerless 47mm ceramic disc valve cartridge with integral hot limit safety stop. Fitting shall be American Standard
Model # 4205.____.____.
GENERAL DESCRIPTION:
Washerless 47mm ceramic disc valve cartridge with integral
hot limit safety stop. Cast brass waterway with 1/2" male inlet
shanks. Cast brass 9-1/4" (235mm) swivel spout, metal
escutcheon plate (escutcheon size 10" L x 2-5/16" W), and
metal handle. 2.2 gpm/8.3L/min. maximum flow rate.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
CSA B 125
NSF 61/Section 9
4205.001
Kitchen faucet. Cast brass waterway with 1/2" male inlet shanks.
Separate handspray.
4205.000
Kitchen faucet. Cast brass waterway with 1/2" male inlet shanks.
Less handspray.
4205.003
Kitchen faucet. Cast brass waterway with 1/2" male inlet shanks.
Handspray through escutcheon.
Product
Number
Description
Polished
Chrome
002
White
Heat
208
Bone
021
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
168mm
(6-5/8)
193
(7-5/8)
235mm
(9-1/4)
127mm
(5)
254mm
(10)
190mm
(7-1/2)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
2.5
3.0
10080604020
21mm
(13/16)
35mm to 38mm
(1-3/8" to 1-1/2")DIA.
MOUNTING HOLE (4 places)
51mm
(2)MAX.
25mm
(1)
SPRAY FOR
4 HOLE SINK
121mm
(4-3/4)
51mm
(2)
203mm
(8)
Finish Options
© 2008 AS America Inc.
A41
