NewAir 9915i Thermostat User Manual



®
Precision Made Easy
Menu Driven Display
2 Heat / 2 Cool
Temperature and Fresh Air Control
Finally a commercial thermostat made with building operators in
mind. Your customers will benefit from maximum comfort and
energy savings.
The i-Series thermostats received the 2003 Frost & Sullivan award for
simple, menu-driven programming that is similar to a cell phone.
Plus you can set optimal fresh air control to meet ASHRAE Indoor Air
Quality Standards. We have also added an adjustable purge control
to bring in fresh air occasionally during periods of non-occupancy.
The 9915i is compatible with all standard 24 Volt AC multi-stage
gas and electric systems, up to two-stage heat and two-stage cool.
We took the guesswork out and put simplicity in. It's programming
made easy.
Integrated Fresh Air Control – Controls fresh air during
occupancy along with programmable purge cycles during
unoccupied periods. Operates as a dry contact or 24V option.
Worry-Free Memory Storage – Even during power outages, the
thermostat maintains setpoint and programmed parameters.
Fully Programmable – 7 day, 5/2, 5/1/1 or 24 hour
programming menus.
Adjustable Events Per Day – 2, 4 or 6 events per day for greater
control of your customer’s comfort.
Adjustable Timed Upstaging – Helps maintain optimal temperature
or energy savings.
Adjustable 1st and 2nd Stage Differential – Maintains optimal
customer comfort.
Remote Indoor and Outdoor Sensor Capable – For greater control of
indoor comfort and system efficiency.
EER
TM
(Energy Efficient Recovery) – Increases energy savings. EER
TM
allows gradual recovery from setback temperature to minimize use of
auxiliary systems.
Programmable Fan – Energy cost savings. Allows user to set and
provide continuous circulation for optimal comfort.
Intermittent Fan – For minimum hourly fan circulation rates for optimal
filtration with minimal energy use.
Technical service available:
1-800-445-8299
M-F 7:00 a.m. - 5:30 p.m. CST
Contractor Friendly
TM
DELUXE
PROGRAMMABLE
THERMOSTAT
9915
i
24 VAC POWERED
EG
ELECTRIC
O
OILGAS
Bilingual Display Option
Set to your customer’s
unique lifestyle and language–
English or Spanish.
Convenient Displays
View a full day of programming
at once for quick review or
easy adjustment.
Conversational Menus
Take programming step by
step in plain, easy to
understand language.
Contractor ID Feature
Set your name and phone number
to remind customers when
service is needed.
Features and Benefits
Fresh Air
Control
